Specifications
| Model | SXJPY 1.0-6.0×1250 | SXJPY 1.0-6.0×1600(1800) | SXJPY 1.0-6.0×2000 |
| Coil Material | Pickling plate | ||
| Coil Thickness | 1.0～6.0mm | 1.0～6.0mm | 1.0～6.0mm |
| Coil Width | 500～1250mm | 500～1600mm(1800mm) | 500～2000mm |
| Coil Weight | ≤20T | ≤25T (28T) | ≤30T |
| Coil I.D | ф508mm ф610mm ф760mm |
ф508mm ф610mm ф760mm |
ф508mm ф610mm ф760mm |
| Coil O.D | ≤ф2000mm | ≤ф2000mm | ≤ф2000mm |
| Cutting Range | 750～6000mm | 750～6000mm | 750～6000mm |
| Cutting Accuracy | ±0.5mm | ±0.5mm | ±0.5mm |
| Line Speed | 0～60m/min | 0～60m/min | 0～60m/min |
| Electrical Control System | PLC Automatic control | ||
