WUXI YuanYang MACHINERY CO.,LTD

★ Cutting accuracy and precision thanks to the machine solidity

★ High quality on flatness

★ High precise cut to length control

★ High quality on cutting

★ High efficiency for production

★ Delightful man-machine interface

Model	JPY0.3-2.0×800	JPY0.3-2.0×1250（1600）	JPY0.5-3.0×1250(1600/2000)
Coil Material	δs≤230N/mm2,Cold-rolled Coil,Stainless Steel Coil,Galvanized Coil
Coil Thickness	0.3～2.0mm	0.3～2.0mm	0.5～3.0mm
Coil Width	300～800mm	800～1250（1600）mm	800～1250mm(1600/2000mm)
Coil Weight	≤10T	≤20T（25T）	≤20T(25T/30T)
Coil I.D	ф508mm	ф508mm	ф508mm(ф610mm)
Coil O.D	≤ф1800mm	≤ф1800mm	≤ф1800mm
Cutting Range	200～3000mm	300～4000mm	400～4000mm
Cutting Accuracy	±0.5mm	±0.5mm	±0.5mm
Line Speed	0～60m/min	0～60m/min	0～60m/min
Electrical Control System	PLC Automatic control
